Electrolytes for Batteries

What are electrolytes for batteries?

Battery electrolytes are a central component of a battery. “Electrolytes” is an imprecise collective term for media that are electrically conductive due to the charged atoms (ions) or charged molecules (ions) that they contain.

Solid Electrolytes, gel Electrolytes, & Liquid Electrolytes (Electrolyte Solution)

Liquid electrolytes

liquid-battery-electrolytes-LOGO
liquid-battery-electrolytes-LOGO

Most battery electrolytes are liquid and are therefore referred to as electrolyte solutions: In lead-acid batteries, for example, it is sulfuric acid, the electrolyte diluted with water, which acts as the solvent. But it can also be molten salts (molten salt) e.g. liquid, inorganic salts (at elevated temperature), as in thermal batteries, or solids (solid electrolyte).-.

In lithium-ion batteries (LIB), water-free organic electrolyte solutions are used. The absence of water makes it possible to store much more energy in LIB’s than in aqueous batteries. In today’s (2023) environmentally friendly electric cars, batteries are installed that mostly use liquid electrolytes. Mobility 4.0 will also only see batteries with liquid electrolytes for the time being.

Similar to lithium-ion, supercapacitors also use anhydrous organic electrolyte solutions.

Solid-State Electrolytes (SSE)

Solid-State Electrolytes
Solid-State Electrolytes

Solid state electrolytes can be electrolytes made of polymers, e.g. (polyelectrolytes) and ceramic inorganic electrolytes (e.g. Garnet electrolytes, LLZO electrolyte or sulfide electrolytes), which conduct lithium ions and sodium ions well.

Inorganic Solid-State Electrolytes (SSE)
Inorganic Solid-State Electrolytes
Inorganic Solid-State Electrolytes

However, solid state electrolytes are the subject of current research and are not yet available as standard in commercial batteries (2023). There is hope to incorporate pure lithium metal into rechargeable LIBs through the use of solid-state electrolytes. Unlike liquid electrolytes, solid-state electrolytes completely prevent the growth of dendrites in the battery cell. This could significantly increase the energy density of lithium-based batteries, which is particularly desired in electric aviation, but also in e-mobility.

Gel electrolytes in polymer batteries
gel-electrolytes-logo
gel-electrolytes-logo

It is also possible to combine ionic polymers (polyelectrolytes, e.g. Nafion) or non-ionic polymers (e.g. Polethylene Oxide, PEO) and solvents as electrolytes, in which case they are referred to as gel electrolytes. Such gel electrolytes are popular because they have the ionic conductivity of liquid electrolytes, but are solid and do not leak. Such battery types are commercially available and are colloquially referred to as “polymer batteries.”

Additives-for-Batteries
Additives-for-Batteries

Additives in the battery electrolyte

Various additives can be added to electrolytes. If an electrolyte is not sufficiently electrically conductive, conductive salts are added to it to improve the electrical conductivity. This is the case in most lithium-ion batteries, for example.

Battery additives usually help to improve the stability of a battery. Many other additives can be added to an electrolyte to improve certain properties in a battery. Wetting battery additives, for example, ensure better wetting of the electrodes with the electrolyte. So-called redox shuttles (redox-active compounds) prevent dangerous chemical reactions from occurring in lithium-ion batteries due to overcharging.

An important factor limiting the performance of lithium-ion batteries is the degradation of the cathode material, which can be caused by dissolution of transition metals, interfacial reactions, loss of contact with conductive particles, and so on. Although all transition metals in the cathode (such as Mn, Ni, Co, Fe, and Zn) are susceptible to dissolution, manganese showed the greatest tendency to decompose.

This is a major reason for the decrease in capacitance in spinel electrodes and other cathodes containing manganese. Metal dissolution leads to structural disorder of the cathode and also the growth and degradation of the SEI layer on the anode.

One way to solve these problems is to use additives that can form an effective surface film
on the cathode. Film-forming cathode additives are designed to oxidize before the solvents and cover the electrode surface to prevent oxidative decomposition of the electrolytes.

Other additives for batteries are used to form polymer-like films on the surfaces of battery electrodes in the hope of preventing the formation of lithium metal dendrites and zinc metal dendrites.
